Fuel Online Density Meter Chemical Density Meter
- Information
- Product Description
- Video
Introduction
The online liquid density meter is a device for continuous online measurement of liquid concentration and density, which can be directly used in industrial production process.
The slurry density meter's advanced technology comes from the differential pressure transmitter based on the capacitive sensor and the pressure relay used in the production process. The precise software of the chemical density meter can accurately measure the density.
Application
1. The measurement of petroleum, natural gas, mining salt,oil refining, oil and water interface detection in the petrochemical industry.
2. The measurement of grape juice, tomato juice, fruit syrup, vegetable oil wine alcohol and soft drink processing in the food and dairy industry.
3. The measurement of black pulp, green pulp, white pulp and alkali solution in the paper industry.
4. The measurement of urea, detergents, ethylene glycol,lubricating oil, acid solution and polymer.
Technical Parameters
Measurement Range: | Density: 0.000 – 5.000 g/cm31 |
Accuracy: | Density 0.5–2 g/cm3 |
Resolution: | ±0.005 g/cm3 |
Calibration Method: | User performed |
Temperature Range (Sample): | 0 – 100 °C (32 – 212 °F) |
Communication: | 4 – 20 mA, HART Protocol |
Display: | Digital LCD |
Operating Environment: | Temperature: -10 – 60°C (14 – 140°F) |
Power Requirements: | 15 – 30 VDC (24 VDC recommended) |
Dimensions: | Individual dimensions vary depending on model, volumetric displacement no more than 0.15 cm3 (0.01 in3) |
